LAPP Cable
Data transmission cable with copper wrapping and PUR outer sheath
UNITRONIC® LiYD11Y: black PUR outdoor data cable, overall copper wrapping screen, PVC cores, DIN 47100, Spiralizable, Flexible -5°C to +70°C, Abrasion resistant
More Information
| Attribute |
Value |
| Product Brand Name |
UNITRONIC® LiYD11Y |
| Approvals |
|
| Extended Description |
Benefits- Increased durability under harsh conditions thanks to robust PUR outer sheath
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
Applications- Intended for use in industrial environments, where cables should have excellent mechanical and chemical resistance.
- Screened cables with small dimensions are suitable for use in computer systems, insturmentation technology, office equipment, balances.
- Can be used in dry or damp rooms
- Outdoor use is possible within the indicated operating temperature range
Features- PUR outer sheath, tear and notch-resistant, resistant to mineral oils and abrasion
- Low-adhesive surface
- Good UV-resistance
- Flame retardant according to IEC 60332-2-2
- Spiral versions with similar properties are also availabe: UNITRONIC® SPIRAL
Product make up- Extra-fine wire strand made of bare copper wires
- Core insulation made of PVC
- Wrapped with bare copper wires
- Outer sheath made of PUR
- Outer sheath colour: black (RAL 9005)
|
| UV Resistant |
Yes |
| Interference rejecting |
Yes |
| Number of conductors |
3 |
| mm2 per conductor |
0.25 |
| Outer Diameter (mm) |
5.3 |
| Copper index kg per km |
15.6 |
| Technical Data |
Core identification code- DIN 47100 without colour repetition
Conductor stranding- Stranded, extra-fine wire
Minimum bending radius- Occasional flexing: 10 x outer diameter
- Fixed installation: 6 x outer diameter
InductivityTemperature range- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
|
| Weight kg per km |
31.0000 |
