LAPP Cable

Screened data transmission cable with colour code acc. to DIN 47100

main product photo
UNITRONIC® LiYCY: Low-frequency PVC data cable DIN 47100 coded Flexible (0.34mm² multi-wire Maxi TERMI-POINT®) Flame retardant Screened, Instrumentation Control
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

Request a quote
More Information
Attribute Value
Product Brand Name UNITRONIC® LiYCY
Approvals
  • Based on VDE 0812
Extended Description Benefits
  • Overall braid minimises electrical interference
  • Multifunctional application possibilities
Applications
  • Screened cables with small dimensions are suitable for use in computer systems, insturmentation technology, office equipment, balances.
  • Dry or damp rooms
Features
  • Flame-retardant according IEC 60332-1-2
Product make up
  • Fine-wire/multi-wire (0.34 mm²) strand made of bare copper wires
  • Core insulation made of PVC
  • Tinned-copper braiding
  • Outer sheath made of PVC
  • Outer sheath colour: grey (similar to pebble grey/ RAL 7032)
Flame Retardant Yes
Interference rejecting Yes
Number of conductors 3
mm2 per conductor 0.5
Outer Diameter (mm) 5.9
Copper index kg per km 38.0000
Technical Data Core identification code
  • DIN 47100 without colour repetition
Conductor stranding
  • Stranded, fine-wire
  • 0.34 mm²: 7-wire
Minimum bending radius
  • Occasional flexing: 15 x outer diameter
  • Fixed installation: 6 x outer diameter
Inductivity
  • approx. 0.65 mH/km
Temperature range
  • Occasional flexing: -5°C to +70°C
  • Fixed installation: -40°C to +80°C
Weight kg per km 55.0000
