Harting

SEK-18 SV MA LP STR55 PR-IN 14P PL2

Connectors, Male connector, Press-in termination, Rated current:1 A, Contacts: 14, Straight, Copper alloy, Nickel plated, Termination side, Au over Pd/Ni, Mating side, Performance level: 2, Thermoplastic resin (PBT), Grey
In stock
£2.65
More Information
Attribute Value
Product Segment SEK Male low profile
Product Family SEK
Product Brand Name 09 18 514 6329
Manufacturer HARTING
Customs tariff number 85366990
Quantity Min 100
Quantity Interval 100
Country of origin RO
Number of poles 14
Material contact surface Nickel
Material of insulation Thermoplast
Direction mating face Standard
Coating plug contact area Nickel (Ni)
Number of rows 2
Type of PCB contacting Press-in
Grid dimensions 2 (mm) 2.54
Suitable for printed circuit board thickness (mm) 1.6
Pin length (mm) 5.5
Material contact Other copper alloys
Fire resistance class V0
Current Rating (A) 1
Temperature Range -55 to 105 Deg. C
