1.673.2000.50
1.673.2000.50
Hummel
Cable gland made of stainless steel with EMC protection for hazardous areas
Cable gland made of stainless steel with EMC protection for hazardous areas Protection class - IP 68 – 10 bar, IP 69 K. Version - short. Seal - NBR
Buy Online
| Attribute | Value |
|---|---|
| Product Brand Name | 1673200050 |
| Weight (kg) | 0.0285 |
| Further information | Elongated threads on request |
| Customs tariff number | 85369010 |
| EAN code | 4033878439203 |
| ETIM 7 | EC000441 |
| Packaging Unit | 10 |
| Height (mm) | 23 |
| Certificates | CE, IECEx, EAC, ATEX, DNV-GL, UL, cUL, INMETRO |
| Version | short |
| External thread (AG) | M20 x 1,5 |
| Material seals / O-rings | NBR |
| Cable diameter (mm) | 10 – 14 |
| Wrench size SW1 / SW2 (mm) | 24/24 |
| Protection class | IP 68 – 10 bar, IP 69 K |
| Material | INOX 1.4305 |
| Seal | NBR |
| Thread length (mm) | 6 |
| Variant | Metric |
| Tightening torque [Nm] | 10 |
| Wrench size 1 (SW1) [mm] | 24 |
| Wrench size (SW) [mm] | 24 |
| Ex-protection level | II 1D Ex ta IIIC Da, II 2G Ex eb IIC Gb |
| Clamping insert | Polyamide V0 according to UL 94 |
| NEMA type rating | 4, 4X, 6 |
| Norms | RoHS, EMV |
| Temperature Range | -60°C to +95°C |
