14010213110160
14010213110160
Harting
har-flexicon 2,54 TSPH-2 T24 WH 500pcs
Connectors, PCB terminal block, Horizontal, Push-in-spring-cage termination, Rated current:6 A, Contacts: 2, Copper alloy, Tin plated, Liquid crystal polymer (LCP), White
In stock
| Attribute | Value |
|---|---|
| Product Segment | har-flexicon |
| Product Family | har-flexicon |
| Product Brand Name | 14 01 021 3110 160 |
| Manufacturer | HARTING |
| Customs tariff number | 85366990 |
| Quantity Min | 1 |
| Quantity Interval | 1 |
| Country of origin | CN |
| Type of packaging | Bulk packaging |
| Number of poles | 2 |
| Material contact surface | Tin |
| Rated voltage (V) | 160 |
| Material of insulation | Liquid crystal polymer |
| Coating plug contact area | Tin (Sn) |
| Number of rows | 1 |
| Type of PCB contacting | Push-in-spring-cage termination |
| Grid dimensions 2 (mm) | 2.54 |
| Material contact | Other copper alloys |
| Fire resistance class | V0 |
| Current Rating (A) | 6 |
| Temperature Range | -40 to 125 Deg. C |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
