14310415402000
14310415402000
Harting
har-flexicon 3,81 FSH-4 GN
Connectors, Connector, Horizontal, Screw termination, Rated current:10 A, Contacts: 4, Copper alloy, Tin plated, Coding: Please order coding pins separately., Polyamide (PA), Polyphthalamide (PPA), Green
Buy Online
| Attribute | Value |
|---|---|
| Product Segment | har-flexicon |
| Product Family | har-flexicon |
| Product Brand Name | 14 31 041 5402 000 |
| Manufacturer | HARTING |
| Customs tariff number | 85366990 |
| Quantity Min | 150 |
| Quantity Interval | 150 |
| Country of origin | IT |
| Type of packaging | Bulk packaging |
| Number of poles | 4 |
| Material contact surface | Tin |
| Rated voltage (V) | 150 |
| Material of insulation | Polyamide |
| Coating plug contact area | Tin (Sn) |
| Number of rows | 1 |
| Type of PCB contacting | Screw termination |
| Grid dimensions 2 (mm) | 3.81 |
| Material contact | Other copper alloys |
| Fire resistance class | V0 |
| Current Rating (A) | 10 |
| Temperature Range | -40 to 110 Deg. C |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
