14310417106000
14310417106000
Harting
har-flexicon 5,08 FPH-4 GN SL
Connectors, Connector, Horizontal, Push-in-spring-cage termination, Rated current:12 A, Contacts: 4, Copper alloy, Tin plated, Coding: Please order coding pins separately., PCB fixing: With screw flange, Polyamide (PA), Polyphthalamide (PPA), Green
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Segment | har-flexicon |
| Product Family | har-flexicon |
| Product Brand Name | 14 31 041 7106 000 |
| Manufacturer | HARTING |
| Customs tariff number | 85366990 |
| Quantity Min | 150.0000 |
| Quantity Interval | 150.0000 |
| Country of origin | IT |
| Type of packaging | Bulk packaging |
| Number of poles | 4.0000 |
| Material contact surface | Tin |
| Rated voltage (V) | 250.0000 |
| Material of insulation | Polyamide |
| Coating plug contact area | Tin (Sn) |
| Number of rows | 1.0000 |
| Type of PCB contacting | Push-in-spring-cage termination |
| Grid dimensions 2 (mm) | 5.08 |
| Assembly | Screw |
| Material contact | Other copper alloys |
| Fire resistance class | V0 |
| Current Rating (A) | 12.0000 |
| Temperature Range | -40 to 110 Deg. C |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
