2170300
2170300
LAPP Cable
Ethernet cable Category 5e, Class D for flexible use - verified up to 100 MHz
Industrial Ethernet cable Cat.5e for flexible use; halogenfree or PUR (AWM-approval) outer sheath material, design 2 or 4 x2xAWG26/7
More Information
| Attribute |
Value |
| Product Brand Name |
ETHERLINE® Cat.5e FLEX |
| Approvals |
- PUR cables: halogenfree acc. to VDE 0472-815
- PVC version with UL/CSA (CMX) certification
- PUR versions: UL AWM Style 21576
- Flame-retardant according IEC 60332-1-2
- halogenfree to IEC 60754-1, IEC 60754-2
|
| Extended Description |
Benefits- Seamless communication from the sensor/actuator level to the Internet
- Screened against interference
- Can be used in dry or damp rooms
- Can be used for Industrial Ethernet in harsh industrial environments
- cables with PUR jacket: 1000 V UL- rating for installation next to power cables
Applications- 2pair: 10/100 Mbit/s for Industrial Ethernet
- 4pair: 10/100/1000 Mbit/s for Industrial Ethernet
- suitable for EtherCAT and EtherNet/IP applications
- For flexible applications (7-wire stranded conductor)
- Only for patch cable applications (max. 60 m)
Features- High-quality, double screening ensures high transmission reliability in areas with electromagnetic interference
- PUR outer sheath is highly resistant to mineral oils and abrasion
Product make up- Stranded conductor, bare, 7-wire
- Core insulation made of foam skin
- 2 or 4-pair version
- SF/UTP: braid of tinned copper wire and plastic laminated aluminum foil as overall screening
- Outer sheath as either PVC, PUR or LSZH
- Colour: water blue (similar to RAL 5021)
- PVC jacket colour: green (similar to RAL 6018)
|
| Halogen free |
Yes |
| Interference rejecting |
Yes |
| Number of conductors |
4x2 |
| AWG per Conductor |
26 |
| Outer Diameter (mm) |
6.1 |
| Copper index kg per km |
25.0000 |
| Characteristic impedance |
nom. 100 Ω acc. to IEC 61156-5 |
| Characteristic impedance |
- nom. 100 Ω acc. to IEC 61156-5
|
| Peak operating voltage |
125 |
| Technical Data |
Minimum bending radius- Fixed installation: 8 x outer diameter
- Flexing: 15 x outer diameter
Test voltage- Core/core: 1000 V
- Core/screen: 500 V
Peak operating voltage voltageCharacteristic impedence- nom. 100 Ω acc. to IEC 61156-5
Temperature range- Fixed installation: -30°C to +80°C
- Flexing: -5°C to +50°C
|
| Weight kg per km |
54.0000 |
