3D2D4G08US4661
3D2D4G08US4661
3D Plus
1.8V, 4 Gbit DDR2 SDRAM organised as 512M x8, based on 128M x8
The 3D2D4G08US4661 is a high-speed highly integrated DDR2 Synchronous Dynamic Random Access Memory containing 4,294,967,296 bits. Each bank has an 8-bit interface and is selected with specific #CS, CKE, #CK, CK and ODT. All other signals are common to the four 1Gbit DDR2 SDRAM memories.
It is particularly well suited for use in high reliability, high performance and high density system applications, such as solid state mass recorder, server or workstation. The 3D2D4G08US4661 is packaged in a 74 pin SOP.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Features |
|
| Product Type | DDR2 SDRAM |
| Memory | 4Gb |
| Power Supply | +1.8 ± 0.1V |
| Pin Assignment | SOP 74 - Pitch 0.65 mm |
| Temperature Range |
|
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
