ETS-Lindgren
5600 Series 9U Rack Mount RF Test Enclosure (21 x 17 x 15 in)
Model 5604 9U Rack Mount RF Test Enclosure
The Model 5604 is a 9U rack-mountable enclosure in the ETS-Lindgren 5600 series, designed for integration into standard 19-inch equipment racks. Providing 80 dB+ of RF isolation from 300 MHz to 18 GHz, it is suited to development, production, and quality assurance testing of wireless devices including Wi-Fi, Bluetooth, Zigbee, RFID, 5G, and IoT technologies.
The 5604 features passive waveguide ventilation with an externally mounted 110 VAC exhaust fan for thermal management during extended testing. Its welded aluminium construction, microwave absorber lining, and dual-layer door with braid-over-foam RF seal ensure reliable RF isolation with minimal reflections. Interchangeable I/O panels provide flexible connectivity options.
Key Features:
- 80 dB+ RF Isolation from 300 MHz to 18 GHz
- 9U Rack-Mountable Format: 53.34 x 43.18 x 38.1 cm (21 x 17 x 15 in)
- Passive Waveguide Ventilation with 110 VAC Exhaust Fan
- Microwave Absorber Lined Interior
- Dual-Layer Door with Braid-Over-Foam RF Seal Rated to 50,000+ Cycles
- Interchangeable I/O Connector Panels (5 Options Available)
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Frequency Range | 300 MHz to 18 GHz |
| Configuration | 9U Rack Mount |
| Shielding effectiveness | 80 dB @ 300 MHz to 3 GHz; 80 dB @ 3 GHz to 6 GHz; 70 dB @ 6 GHz to 18 GHz |
| Outer dimensions ( Lx W x H) | 53.34 cm x 43.18 cm x 38.1 cm (21 in x 17 in x 15 in) |
