Hummel

Crimp pin 2mm, machined

7.015.952.001 - Crimp pin 2mm, machined Also known as 7015952001. . Minimum mating cycles : > 500
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Product Brand Name 7015952001
Manufacturer Hummel
Additional Description
  • Characteristic of connection : Crimp
  • Color contact insert :
  • Contact-Ø signal [mm] : 2
  • Degree of Protection :
  • Dip solder contacts length [mm] :
  • Flammability CE :
  • Insert : Pin
  • Insulation resistance signal :
  • Material insulating body :
  • Max. contact resistance signal :
  • Nominal voltage at degree of pollution 3 signal :
  • Nominal current signal :
  • Number of contacts power :
  • Number of poles :
  • Pole picture :
  • Temperature range :
  • Test voltage signal [v-] :
Length (mm) 37.0000
Weight (kg) 0.00175
Customs tariff number 85366990
EAN code 4033878502556
ETIM 7 EC000796
Packaging Unit 100
Characteristic of connection Crimp
Insert Pin
Signal contact diameter (mm) 2.0000
Minimum mating cycles > 500
Crimp range 1 – 4 mm²
Material contact surface nickel, gold plated (0.25 µm)
Contact diameter 2 mm
Crimp contact Crimp pin signal 2 mm machined
Contact diameter crimping range (mm) 3.4
Material contact Copper-zinc  alloy
Cross section 0.75 – 4 mm²
Suitable crimping tool 7000900919, 7000900920
More Information
Attribute Value
Data Sheet Click here to view
