AMM-7200
AMM-7200
Marki Microwave
12 GHz – 46 GHz GaAs Driver Amplifier
The AMM-7200 is a general-purpose broadband MMIC driver amplifier that provides +21 dBm output power suitable for driving a Marki H or L diode mixer at 12-46 GHz and S diode mixer from 14‑40 GHz. The amplifier also has excellent return losses and a small die size which allows it to be used in a variety of applications. It has built in DC-blocking capacitors on the input and output.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Minimum Frequency | 12 |
| Minimum Input Power for Saturation [dBm] | +6 |
| Maximum Input Power for Saturation [dBm] | +12 |
| Saturated Output Power [dBm] | +21.5 |
| Small Signal Gain [dB] | 18 |
| OIP3 [dBm] | +29 |
| Amplifier Type | LO Driver Bare Die/Modules |
| Package | Bare Die and Module |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
