APM-7098
APM-7098
Marki Microwave
0.1GHz – 22GHz Low Phase Noise Amplifier
The APM-7098 is a broadband distributed, low phase noise LO driver amplifier designed to provide a saturated +23 dBm output power with low DC power consumption. This amplifier uses GaAs HBT technology for low phase noise, and is optimized to provide enough power to drive the LO port of an S-diode mixer from 100 MHz to 18 GHz or of an H or L diode mixer from 100 MHz to 22 GHz. This amplifier can be operated with a variety of bias conditions for both low power and high-power applications.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Minimum Frequency | 0.1 |
| Minimum Input Power for Saturation [dBm] | +10 |
| Maximum Input Power for Saturation [dBm] | +16 |
| Saturated Output Power [dBm] | +23 |
| Small Signal Gain [dB] | 14 |
| OIP3 [dBm] | +24 |
| Amplifier Type | LO Driver Bare Die/Modules |
| Package | Bare Die and Module |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
