AT37P-37861-B
AT37P-37861-B
Aaren Technology
Replaceable Pin, 2.92mm F, Pin: 0.30mm/0.012"
Aaren Technology 2.92mm Connectors are 50Ω precision connectors. They are designed with excellent characteristics over the full frequency range up to 40GHz. 2.92mm connectors are mechanically compatible with 3.5mm, SMA connectors.
Please note: There is a minimum order quantity of 10 for this item. Price breaks are available for higher quantities - please ask a member of our team for details on 0330 313 3220, or email [email protected].
In stock
| Attribute | Value |
|---|---|
| Connector Family | 2.92mm Connectors (DC-40GHz) |
| Weight | 0.005 |
| Impedance | 50Ω |
| Frequency | DC-40GHz |
| VSWR Max | 1.15:1 |
| Durability | 500 Cycles |
| Temperature Range | -55˚C ~ +165˚C |
| Material Finishing |
Housing: Stainless Steel SU303 (Polished/Passivated) |
| Interface | 2.92mm Per MIL-STD-348A |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
