21033961505
21033961505
Harting
PCB receptacle male L-coded (60 pcs)
Connectors, PCB adapter, Straight, Reflow soldering termination (THR), Rated current:16 A, Contacts: 4, Copper alloy, Gold plated, Coding: L-coding, Polyamide (PA), Grey
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Segment | M12 Power |
| Product Family | Circular Connectors |
| Product Brand Name | 21 03 396 1505 |
| Manufacturer | HARTING |
| Customs tariff number | 85366990 |
| Quantity Min | 60.0000 |
| Quantity Interval | 60.0000 |
| Country of origin | RO |
| Type of packaging | 60 pieces in a tray |
| Number of poles | 4.0000 |
| Material contact surface | Gold |
| Rated voltage (V) | 63.0000 |
| Contact design | Pin |
| Material of insulation | Polyamide |
| Coating plug contact area | Gold (au) |
| Type of PCB contacting | THR connection |
| Material contact | Other copper alloys |
| Current Rating (A) | 16.0000 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
