E36102B
E36102B
Keysight Technologies
DC power supply, single-output, 6 V, 5 A, 30 W
Keysight E36100B Series basic DC power supplies feature a compact size (2U, ¼-rack), a high-contrast OLED display that is viewable from any angle, and modern USB and LAN (LXI Core) connectivity. Use the highly accurate low-current measure feature for demanding measurements. Protect your DUT with built-in overvoltage and overcurrent protection, and count on the built-in overtemperature protection to keep your power supply safe. Get connected to your instrument quickly via the intuitive front-panel interface, a Web interface running on a browser, a SCPI or IVI program, Keysight IO Libraries, or a BenchVue app running on your PC or mobile device. Choose the best model for your needs: five models offer up to 5 A or 100 V.
Clean, reliable power supply
- Low, normal mode noise specifications assure quality power for precision circuitry applications enabling you to power your design with confidence
- Accurate voltage/current programming and read back capability provides excellent control to precisely power your device under test
- Protection for your device under test (DUT) includes overvoltage, overcurrent, and overtemperature protection
Convenient benchtop capabilities
- USB and LAN (LXI Core)
- BenchVue software support and Web interface control
- Save space on your bench, 2U ¼ rack
- Easily view the high contrast OLED display
- Intuitive on-screen menu
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Options |
Calibration Documentation
|
| Key Features |
Output rating: 30 W
Programming accuracy: ± (% of output + offset)
Ripple & noise (20 Hz to 20 MHz)
Readback accuracy: ± (% of output + offset)
|
| Power | 30 W |
| Outputs | Single Output |
| Voltage | 6 V |
| Current | 5 A |
| Additional Services |
KeysightCare Service Plan OC
|
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
