E3644A
E3644A
Keysight Technologies
DC power supply, dual range: 0-8V/ 8 A and 0-20V/ 4 A, 80 W. GPIB, RS-232
The E3644A 80 W bench power supply has dual-range flexibility with a low and high voltage range. The low-voltage range allows the power supply to output more current. The E3640 Series has models with single and dual outputs—automate tests with GPIB or RS232.
Programming accuracy (@ 25°C ±5°C), ±(% output + offset)
- Voltage: <0.05% + 10 mV (<0.1% + 25 mV for output 2 of E3646/47/48/49A)
- Current: <0.2% + 10 mA
Ripple & noise 20 Hz to 20 MHz
- Normal Mode Voltage: <5 mVpp / 0.5 mVrms
- Normal Mode Current: <4 mArms
Readback accuracy (@ 25°C ±5°C), ±(% output + offset)
- Voltage: <0.05% + 5 mV (<0.1% + 25 mV for output 2 of E3646/47/48/49A)
- Current: <0.15% + 5 mA (<0.15% + 10 mA for output 2 of E3646/47/48/49A)
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries, call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Options |
Input Voltage
|
| Key Features |
Output ratings (@ 0°C to 40°C)
|
| Outputs |
|
| Power | 80 W |
| Voltage | 0-8 V, 0-20 V |
| Current | 8 A, 4 A |
| Additional Services |
KeysightCare Service Plan OC
|
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
