ETS-Lindgren
Single Axis Positioner
Light Duty Azimuth Positioner for Antenna Pattern Measurements
ETS‑Lindgren’s Model 2006 Light Duty Azimuth Positioner is designed to provide azimuth rotation of a lightweight test object. It is intended primarily as a basic solution for azimuth (polar) pattern measurements of passive and active devices.
The Model 2006 is fully compatible with ETS‑Lindgren’s EMQuest™ & EMQuest Lite Antenna Pattern Measurement Software for passive antenna pattern measurement. For pattern measurement of active devices, a software upgrade to the fully functional standard EMQuest EMQ-100 Antenna Pattern Measurement Software is recommended. A USB 2.0 data connection to the EUT is supplied via slip ring for continuous rotation.
Key Features:
- USB 2.0 Data Connection via Slip Ring
- Continuous Rotation Capability
- Compatible with EMQuest™ Software
- Designed for Lightweight Test Objects
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Voltage | 208/230 VAC, 50/60 Hz |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
