Erzia

Ka Band Low Noise Amplifier

The ERZ-LNA-1770-2200-70-2 is a Ka Band low noise amplifier with a high gain value of 70 dB and a noise figure lower than 2 dB. This amplifier also includes an output isolator.
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Applications
  • Industrial
  • Laboratory
  • Satcom
  • Telecom
  • Space
  • Aerospace
  • Military
Frequency Start (GHz) 17.7
Frequency Stop (GHz) 22.0000
Power Supply (V) 18± 2V
Current (mA) 166
Storage Temperature -45°C to 85°C
Band Ka Band
Output Power (dBm) 12
Gain (dB) 73
Operating Temperature -35°C to 70°C
Connectors IN: WR42 (2.92 mm also available)
OUT: 2.92 mm Female
Product Type Low Noise Amplifier
Dimensions 88.9 x 50 x 31.4 mm
More Information
Attribute Value
Data Sheet Click here to view
