ERZ-LNA-4720-5140-15-3.5

ERZ-LNA-4720-5140-15-3.5

ERZ-LNA-4720-5140-15-3.5

Erzia

V Band Low Noise Amplifier

The ERZ-LNA-4720-5140-15-3.5 is a V band low noise amplifier providing a gain of 15 dB and a noise figure below 3.5 dB. The compact size and modularity makes it ideal for a wide range of applications.
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Applications
  • Industrial
  • Laboratory
  • Satcom
  • Telecom
  • Space
  • Aerospace
  • Military
Frequency Start (GHz) 47.2
Frequency Stop (GHz) 50.0000
Power Supply (V) 12± 1V
Current (mA) 79
Storage Temperature -55°C to 125°C
Band V Band
Output Power (dBm) 1.5
Gain (dB) 15
Operating Temperature -55°C to 85°C
Connectors WR19
Product Type Low Noise Amplifier
Dimensions 40 x 30 x 32..5 mm
More Information
Attribute Value
Data Sheet Click here to view
