FACT 3 EMC Anechoic Chamber - 3 m Range Full Compliance Testing
FACT™ 3 Meter EMC Chamber
The ETS-Lindgren FACT 3 provides semi-anechoic radiated emissions and fully anechoic radiated immunity compliance testing for most international EMC regulations. Its compact footprint uses hybrid absorber and ferrite tile, fitting into many existing structures while supporting 4-metre antenna scans above the ground plane. Compatible with LoProTM and EuroProTM turntables, eliminating pit excavations.
Quiet zones up to 2.0 m diameter are available. DuraSorb absorber withstands continuous field intensity up to 200 V/m and intermittent up to 500 V/m. NSA performance options from ±4.0 dB (Standard) to ±3.0 dB (Premium) are available.
Key Features:
- 26 MHz to 40 GHz Frequency Range
- Full Compliance RE: ANSI C63.4, FCC Parts 15/18, CISPR 11/16/22, EN 50147-2, VCCI, SAE J551/J1113
- Full Compliance RI: IEC 61000-4-3, SAE J551/J1113
- NSA Options: Standard ±4.0 dB, Standard Plus ±3.5 dB, Premium ±3.0 dB
- Eligible for FCC 3 Meter Class B Facility Filing
- Available as Turnkey Package
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Frequency Range | 26 MHz to 40 GHz |
| Features |
|
| Immunity Frequency Range | 26 MHz to 18 GHz |
| Emissions Frequency Range | 30 MHz to 40 GHz |
| Outer dimensions ( Lx W x H) | 9.04 m x 6.71 m x 6.12 m |
