HI-6110PQMF
HI-6110PQMF
Holt Integrated Circuits
HI-6110 Series MIL-STD-1553 CMOS Integrated Circuit
The HI-6110 is a CMOS integrated circuit designed to implement the MIL-STD-1553 protocol between a host processor and a dual redundant MIL-STD-1553 data bus. The single chip architecture contains all the necessary logic and memory to process and store the data and command words for one complete MIL-STD-1553 message. In addition, the chip also includes the analog transceivers. The HI-6110 may be configured as a Bus Controller (BC), a Remote Terminal (RT), an addressed Monitor Terminal (MT) or an unaddressed MT. Registers are provided to store both incoming and outgoing command words. Incoming and outgoing data word storage is provided by 32-word FIFOs. The HI-6110 is available in a small, 64-pin plastic chip-scale package (QFN) or a 52-pin plastic quad flat pack (PQFP).
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
HI-6110PQMF Specifications
- Monolithic CMOS Technology
- Exceptional Low Power
- On-chip Message Buffering
- 3.3V Single Supply Operation
- Compliant to MIL-STD-1553 Notice 2 and MIL-STD-1760 Stores Management
- Selectable Master Clock Frequency
- On-chip Dual Transceivers
- Bus Controller / Remote Terminal / Bus Monitor Mode Selection
- Smallest Footprint Available in 64-Pin 9mm x 9mm Plastic Chip-scale Package
- Also Available in a 52-pin Plastic QFP Option
- Industrial & Extended Temperature Ranges Available
| Attribute | Value |
|---|---|
| RoHS | Yes |
| Product Type | MIL-STD-1553 Integrated Terminal ICs |
| Package Description | 52 Pin Plastic Quad Flat Pack (MQFP) |
| Moisture Sensitivity Level | 3.0000 |
| Product Longevity | > 10 years |
| Applications |
|
| Flow | M |
| Theta JA (°C/W): | 37.19 |
| Theta JB (°C/W): | 21.69 |
| Temperature Range | -55°C to +125°C |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
