HI-8482 Series ARINC 429 Line Receiver
The HI-8482 bus interface unit is a silicon gate CMOS device designed as a dual differential line receiver in accordance with the requirements of the ARINC 429 bus specification. The device translates incoming ARINC 429 signals to normal CMOS/TTL levels on each of its two independent receive channels. The HI-8482 is also functionally equivalent to the Fairchild/Raytheon RM3183.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
HI-8482PST Specifications
- Converts ARINC 429 Levels to Digital Data
- Direct Replacement for the RM3183
- Greater Than 2 Volt Receiving Hysteresis
- TTL and CMOS Outputs and Test Inputs
- Industrial & Extended Temperature Ranges Available
- 20-Pin SOIC, PLCC, CERQUAD, DIP & LCC Packages Are Available
| Attribute | Value |
|---|---|
| RoHS | No |
| Product Type | ARINC 429 Line Receivers |
| Package Description | 20 Pin Plastic SOIC - WB |
| Moisture Sensitivity Level | 1.0000 |
| Product Longevity | > 10 years |
| Applications |
|
| Flow | T |
| Theta JA (°C/W): | 49.3 |
| Temperature Range | -55°C to +125°C |
