HI-8684PSTF
HI-8684PSTF
Holt Integrated Circuits
HI-8684 Series Protocol IC with Parallel Interface
The HI-8683 and HI-8684 are system components for interfacing incoming ARINC 429 signals to 8-bit parallel data using proven +5V analog/digital CMOS technology. The HI-8683 is a digital device that requires an external analog line receiver such as the HI-8482 or HI-8588 between the ARINC bus and the device inputs. The HI-8684 incorporates the digital logic and analog line receiver circuitry in a single device.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
HI-8684PSTF Specifications
- Automatic Conversion of Serial ARINC 429, 575 & 561 Data to 8-Bit Parallel Data
- High-Speed Parallel 8-Bit Data Bus
- Error Detection - Word Length and Parity
- Reset Input for Power-On Initialization
- On-Chip Line Receiver Option (HI-8684)
- Internal Lightning Protection of ARINC inputs in accordance with DO-160D, Level 3 (HI-8684-10 only)
- Input Hysteresis of at Least 2 Volts (HI-8684)
- Test Inputs Bypass Analog Inputs (HI-8684)
- Simplified Lightning Protection With the Ability to Add 10 Kohm External Series Resistors
- Plastic Package Options - Surface Mount (SOIC), PLCC and DIP
- Industrial & Extended Temperature Ranges Available
| Attribute | Value |
|---|---|
| RoHS | Yes |
| Product Type | ARINC 429 Protocol ICs with Parallel Interface |
| Package Description | 20 Pin Plastic SOIC - WB |
| Moisture Sensitivity Level | 1.0000 |
| Product Longevity | > 10 years |
| Applications |
|
| Flow | T |
| Theta JA (°C/W): | 49.3 |
| Temperature Range | -55°C to +125°C |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
