INM-6700

INM-6700

Focus Microwaves

Input Noise Module (67 GHz)

Noise measurements allow the determination of the four Noise Parameters of a device (transistor). Focus’ Noise Modules integrate well with various third party noise receivers.

Noise Parameters: These are four numbers that fully describe the noise behaviour of an active or passive device (twoport) at a given frequency. For practical reasons we use the following quantities as Noise Parameters:

Focus’ noise parameter extraction routines leverage the PNA-X’s unique implementation
of the cold-source noise figure measurement technique. This specific technique requires a noise source to determine the kBG (gain-bandwidth constant) of the system and a passive mechanical tuner is used to characterize the noise receiver across both the impedance and frequency space. This step is imperative to obtain fully vector-source-corrected measurements.

Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Frequency up to 67 GHz
Insertion Loss (dB) 1.12
VSWR 1.9
Connectors 1.85 mm
Product Type Input Noise Module
More Information
Attribute Value
Data Sheet Click here to view
