LTC-10640-RS422
LTC-10640-RS422
ETS-Lindgren
LTC Data Filter, 10 x 0.06 A, 0-277/480 VAC, RS422 passband
ETS-Lindgren LTC Data Filter
Ideal for communication lines entering or leaving shielded rooms, computer rooms, communication terminal rooms, and SCIFs.
Key Features:
- 2 to 12 line LTC filter configurations
- Signal, sensor, voice communication, data communication, and control line applications
- RS232, RS422, and 10M data passband options
- Stand-alone, individual mounting
- Optional threaded conduit pipe for shielded enclosure penetration
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Dimensions | 38.3 cm (15.25 in) x 45.72 cm (18 in) x 5.1 cm (2 in) (L x W x H) |
| Weight | 25 lbs |
| Current Rating | 2 X 0.06 A |
| Configuration |
These Filters Canisters Can Come Without Penetration |
| Impedance | RS422 |
| Power Voltage | 0-277/480 VAC |
| Operating Voltages | 0-277/480 VAC |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
