MBAL-1445SM
MBAL-1445SM
Marki Microwave
MMIC Isolation Balun (14 GHz - 45 GHz)
MBAL-1445 is a high isolation MMIC balun. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances result in less unit to unit variation than traditional balun technologies, allowing for accurate simulations using the provided S3P file taken from measured production units.
Baluns are passive reciprocal devices allowing either single ended to differential or differential to single ended conversion. The MBAL-1445SM is available as a 4 X 4 mm QFN package. Evaluation boards are also available.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| RoHS | Y |
| Key Features |
|
| Phase Balance Degrees | 2.0000 |
| Maximum Frequency | 45 GHz |
| Isolation (dB) | 18 |
| Minimum Frequency | 14 GHz |
| Product Type | High Isolation |
| Insertion Loss (dB) | 4.5 |
| Amplitude Balance (dB) | 0.2 |
| Common Mode Rejection (dB) | 33.0000 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
