MC16-0222SM
MC16-0222SM
Marki Microwave
Stripline Directional Coupler (2 GHz - 22 GHz)
MC16-0222SM is a MMIC 2-22 GHz Directional Coupler. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions.
Tight fabrication tolerances result in less unit to unit variation than traditional coupler technologies, allowing for accurate simulations using the provided S3P file taken from measured production units.
The MC16-0222SM is available as a 4 X 4 mm QFN package. Evaluation boards are also available.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| RoHS | Y |
| Key Features |
|
| Directivity (dB) | 19 dB |
| Maximum Frequency | 22 GHz |
| Minimum Frequency | 2 GHz |
| Product Type | |
| VSWR | 1.22 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
