MEQ3-20ACH Marki Microwave | APC Technology Group

MEQ3-20ACH

MEQ3-20ACH

Marki Microwave

Passive GaAs MMIC Equaliser (DC - 20 GHz)

The MEQX-20ACH family of passive MMIC equaliser die are an ideal solution for compensating for low pass filtering effects in RF/microwave and high speed digital systems. They provide positive slope from DC to 20GHz with DC attenuation options between 3 and 11dB.

The unique design offers superior return loss to competitors. GaAs MMIC technology provides consistent unit-to-unit performance in a small, low cost form factor.

Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Key Features
  • DC attenuation options from 3 to 11dB
  • Typical Insertion Loss 0.4dB at 20GHz
  • VSWR < 1.3:1 Over Entire Band
Return loss 21 dB
Maximum Frequency 20 GHz
Minimum Frequency DC
Applications
  • RF Transceivers
  • High-Speed Data
  • Telecom
  • Cable Loss Compensation
  • Amplifier Compensation
RoHS Y
More Information
Attribute Value
Data Sheet Click here to view
