MEQ6-70ACH

MEQ6-70ACH

Marki Microwave

Passive GaAs MMIC 70 GHz Equaliser

Bare Die Passive MMIC Equaliser, 6dB DC Attenuation

The MEQ6-70ACH passive MMIC Equaliser die is an ideal solution for compensating for low pass filtering effects in RF/microwave and high speed digital systems. It provides positive slope from DC to 70GHz with 6 dB DC attenuation.

The unique design offers superior return loss to competitors. GaAs MMIC technology provides consistent unit-to-unit performance in a small, low cost form factor.

MEQ6-70ACH Applications:

  • RF Transceivers
  • High-Speed Data
  • Telecom
  • Cable Loss Compensation
  • Amplifier Compensation
  • 5G
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Product Family Equalisers
Size 1.25 x 1.1 mm
Key Features
  • 4 dB, 6 dB, 8 dB, 10 dB DC attenuation options available
  • Typical insertion loss 1.4 dB at 70 GHz
  • Return loss better than 20 dB over entire band
Minimum Frequency 0 GHz
Package Bare Die
More Information
Attribute Value
Data Sheet Click here to view
