MFBP-00045CH
MFBP-00045CH
Marki Microwave
Passive GaAs MMIC 23.99 - 28.75 GHz Bandpass Filter
Bare Die Passive MMIC Bandpass Fixed Filter, 23.99 - 28.75 GHz
The MFBP-00045CH passive MMIC bandpass filter die is an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions.
Tight fabrication tolerances allow for less unit to unit variation than traditional filter technologies. The MFBP-00045CH is available as a wire bondable chip. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Product Family | Fixed_Filters |
| Size | 3.10 x 3.10 mm |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
