MMIQ-0205HSM
MMIQ-0205HSM
Marki Microwave
MMIC Double-Balanced IQ Mixer
The MMIQ-0205SSM is a miniaturized, surface-mount multi-octave 1.75-5.0 GHz IQ mixer. It features matched double balanced mixers connected with an integrated LO hybrid and RF power divider. It can be used for either upconversion or downconversion. Applications include communications or radar systems with advanced digital modulation formats and phase modulated signals, test and measurement, or electronic warfare.
Image reject or single sideband modulation with excellent suppression is possible with use of an external IF quadrature (90°) hybrid.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| Key Features |
|
| IF (GHz) | DC to 2 |
| LO Drive (dBm) | +14 to +20 |
| Conversion Loss (dB) | 8 |
| Isolations L-R (dB) | 61 |
| Isolations L-I (dB) | 46 |
| RF/LO (GHz) Low | 1.75 |
| RF/LO (GHz) High | 5 |
| Image Rejection (dB) | 32 |
| Product Type | MMIC Surface Mounts |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
