MMIQ-1867LSM
MMIQ-1867LSM
Marki Microwave
Low LO Drive Surface Mount MMIC IQ Mixer
The MMIQ-1867LSM is a low LO drive, passive GaAs MMIC IQ mixer. This is an ultra-broadband mixer spanning 18 to 67 GHz on the RF and LO ports with an IF from DC to 23 GHz.
Up to 50 dB of image rejection is available due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid.
Both surface QFNs and evaluation boards are available.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Download The Marki Microwave Product Brochure
View Marki Microwave's full product range of RF, Microwave & mmWave Components Bare Die, Surface Mount and Connectorised DC to 140GHz.
| Attribute | Value |
|---|---|
| Applications |
|
| IF (GHz) | DC to 23 |
| LO Drive Min (dBm) | +8 to +19 |
| Conversion Loss (dB) | 9 |
| Isolations L-R (dB) | 48.5 |
| Isolations L-I (dB) | 43 |
| RF/LO (GHz) Low | |
| RF/LO (GHz) High | |
| Image Rejection (dB) | 32 |
| Product Type | MMIC Surface Mounts |
