MMPX-00002PSM
MMPX-00002PSM
Marki Microwave
Passive MMIC DC-18 GHz Quadplexer
The MMPX-00002PSM is a MMIC surface mount quadplexer capable of multiplexing DC-6 GHz / 8-10 GHz / 12-14 GHz / 16-18 GHz signals. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions.
Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MMPX-00002PSM is available as a 6x6mm QFN. Low unit to unit variation allows for accurate simulations using the provided SnP files taken from measured production units.
MMPX-00002PSM Applications:
- Satellite Communications
- Reflectionless Filter Applications
- Electronic Warfare
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Family | Diplexers |
| Size | 6 x 6 mm |
| Key Features |
|
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
