MPD-0226CH
MPD-0226CH
Marki Microwave
2-way Wilkinson Microwave / RF Power Divider / Combiner (2 GHz - 26.5 GHz)
MPD-0226CH is a MMIC 2-way Wilkinson power divider. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions.
Tight fabrication tolerances result in less unit to unit variation than traditional power divider technologies. Low unit to unit variation allows for accurate simulations which include the effects of the bond wires for the die and the housing for the module.
Power dividers are passive reciprocal devices that can be used either as power combiners or as power dividers. Applications include Radar, Satcom, EW and test equipment. The MPD-0226CH is available as a bare die.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| Insertion Loss | 1.5 dB |
| Isolation | 20 dB |
| Maximum Frequency | 26.5 GHz |
| Minimum Frequency | 2 GHz |
| Product Type | |
| RoHS | Y |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
