MQS-0518SM
MQS-0518SM
Marki Microwave
MMIC 90° Splitter / Combiner (5 - 18 GHz)
The MQS-0518SM is a MMIC 5 GHz – 18 GHz 90° splitter/combiner. Passive GaAs MMIC technology allows production of smaller constructions that replace larger form factor circuit board constructions. Low variation allows for accurate simulations using the provided S4P file taken from measured production units.
Tight fabrication tolerances allow for less unit to unit variation than traditional splitter/combiner technologies. The MQS-0518SM is available as 4X4 mm QFN Package. Evaluation boards are also available. A
pplications include single sideband upconverters, image rejection downconverters, IQ modulators, balanced amplifiers, microwave correlators. The MQS-0518SM is not recommended for applications involving reflected signals.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| RoHS | Y |
| Key Features |
|
| Isolation | 17 dB |
| Maximum Frequency | 18 GHz |
| Minimum Frequency | 5 GHz |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
