MT3A-0113H
MT3A-0113H
Marki Microwave
Two-Tone-Terminator Mixer/LO-Amplifier
The MT3A-0113H is a versatile, robust, and broadband Two-ToneTerminator mixer integrated with a low phase noise LO driver amplifier. The MT3A-0113H employs the most sophisticated mixer on the market today and offers unparalleled performance when compared to all other mixer technologies.
The MT3A-0113H delivers exceptional IMD suppression with low conversion loss and high IP3. The integrated positive bias only LO amplifier allows for high linearity with LO drive levels down to just +5dBm.
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Key Features |
|
| IF (GHz) | 0.5 to 8.5 |
| LO Drive Min (dBm) | +3 to +15 |
| Conversion Loss (dB) | 9.5 |
| RF/LO (GHz) Low | 1 |
| RF/LO (GHz) High | 13 |
| IIP3 (dBm) | +28 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
