ONM-6700

ONM-6700

Focus Microwaves

Output Noise Module (67 GHz)

Noise measurements allow the determination of the four Noise Parameters of a device (transistor). Focus’ Noise Modules integrate well with various third party noise receivers.

Noise Parameters: These are four numbers that fully describe the noise behaviour of an active or passive device (twoport) at a given frequency. For practical reasons we use the following quantities as Noise Parameters:

Focus’ noise parameter extraction routines leverage the PNA-X’s unique implementation
of the cold-source noise figure measurement technique. This specific technique requires a noise source to determine the kBG (gain-bandwidth constant) of the system and a passive mechanical tuner is used to characterize the noise receiver across both the impedance and frequency space. This step is imperative to obtain fully vector-source-corrected measurements.

Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Gain (dB)
  • 29 for ≤26.5 GHz
  • 28.5 for 26-40 GHz
  • 28 for 40-50 GHz
  • 21 for 50-65 GHz
Frequency up to 67 GHz
VSWR Max 3:1
Connectors 1.85 mm
Product Type Output Noise Module
More Information
Attribute Value
Data Sheet Click here to view
