PW9251A

The PW9251A PathWave IV Curve Measurement software accelerate your research, development and design verification by quick and easy execution of synchronous current-voltage (IV) measurements without programming, immediately reviewing test results on graphs and tables, and generating report efficiently.

Synchronous Current-Voltage (IV) Measurements With Graphical Results

The PathWave IV curve is a ready-made GUI software to perform a variety of synchronous current voltage (IV) measurements on up to 40 1 channels without programming. Various analysis functions on graphs and tables allow users to review test results immediately after the measurement. Export functions of graphs with markers and tables support efficient reporting. In addition, the test result files contain all the settings, allowing users to review and repeat the test accurately.

The Keysight PW9251A PathWave IV curve accelerates your research, development, and design verification with increasing productivity, enabling more accurate and reliable data acquisition and more efficient use of the equipment.

Powerful setup menu for maximum flexibility

The PW9251A setup menu allows you to specify and preview the settings on multiple SMU channels before you perform a measurement, giving you the flexibility and ease of setting up the SMU channels.

Improve efficiency with the built-in graph function

The PW9251A built-in graph function supports basic and advanced features, enabling immediate review of the test results through graphs with markers.

Post-processing at ease

View numerical measurement results in a table format. You can easily export these data into an Excel spreadsheet for post-analysis

Keysight PW9251A PathWave IV Curve Highlights:

• Easily and quickly performing synchronous current-voltage (IV) measurements without programming
• Immediately reviewing test results on graphs with markers and tables
• Efficiently making reports or post-processing by exporting graphs in image files and tables in CSV files
• Easily repeating/reviewing the test result by loading/saving the test results with entire test setups
• Experience the full range of the application's capabilities without the need for a software license by previewing its features in Demo Mode
• Includes API functions to facilitate integration into your programming environment
