Durridge
Next-Generation Professional Electronic Radon Monitor
The all-new RAD8: rugged and sensitive
The Durridge RAD8 reimagines scientific-quality electronic radon monitors with complete top-to-bottom upgrades in comparison to the venerable RAD7. With its cutting-edge features and optimisations for outdoor use, RAD8 revolutionises radon/thoron monitoring in the field and the lab.
Built for harsh environments
An environment-proof, super portable design with long battery life and IP67 water/dust resistance (even when the lid is open) means you can use RAD8 conveniently and worry-free whether you work near water, on rugged terrain, in a dusty mine, or the gentle confines of a lab.
New patent-pending technology boosts sensitivity 70% higher than RAD7, significantly reducing data uncertainty. RAD8 provides unparalleled access to spectrometry data (including raw sensor counts) so users can analyse and verify measurements in detail.
Superior accuracy
RAD8’s high-resolution alpha spectrometry precisely measures alpha particle energies, enabling it to clearly identify the characteristic alpha energy peaks from the radon and thoron decay chains. This event-by-event species discrimination provides accuracy superior to other technologies such as pulsed ionization chambers and Lucas cells. Radon and thoron are measured independently and simultaneously, without interference – background from the buildup of long-lived decay products that plague other products is rejected from RAD8’s radon/thoron measurements. No matter how long you have owned your RAD8, background will never interfere with your measurements. RAD8 can also recover from high radon concentrations in minutes, rather than hours, to dramatically save time, money, and boost productivity.
Easy-to-operate
The easily navigated, high-visibility colour touchscreen and pushbutton controls let you operate the RAD8 in any conditions, even with gloves on, perfect for measuring Radon in air, water and soil, in homes and buildings, mines and deserts, on the ocean and volcanoes. While the touchscreen provides control over instrument and measurement settings, the RAD8 is delivered with pre-programmed testing protocols to get you up and running quickly. The IATA-compliant rechargeable battery keeps RAD8 running continuously for three days and built-in wireless networking makes data download easier than ever.
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Modes Of Operation |
RAPID mode calculates radon concentration from counts of the polonium-218 alpha peak in the A Window. PRECISE mode calculates radon concentration from counts of polonium-218 and polonium-214 in the A and C windows to achieve higher statistical precision. AUTOMATIC mode switches from Rapid to Precise mode after three hours of continuous measurement to combine the benefits of rapid response and statistical precision. RAD H2O modes work with the Durridge RAD H2O water accessory kit to measure radon concentrations in aerated water samples of specific volumes. |
| Test Protocols |
SNIFF protocol applies the Rapid analysis mode to continuously pumped air samples for spot readings. 1-day and 2-day protocols apply the Automatic analysis mode to air samples pumped with a Standard 40% duty cycle for 24-hr or 48-hr, respectively. Continuous protocol applies the Automatic analysis mode to air samples pumped indefinitely with a Standard 40% duty cycle. Grab protocol applies the Rapid analysis mode for 20-min to air samples that are briefly pumped into the chamber. H2O 40-ml and 250-ml protocols apply the Rapid analysis mode for 20-min to air samples that are briefly pumped into the chamber from Durridge water accessories. |
| Data Storage | 16 GB holds millions of records, each with full sensor and spectrum data. |
| Sample Pumping | Built-in 0.6 L/min air sample pump with bypass option for external pumping |
| Connectivity | Wi-Fi, 2 USB ports, COM port, Accessory port |
| Audio Output | Multiple audio output options for real-time communication of detection events |
| Tamper Resistance | Password-protected lock screen secures RAD8 against tampering; RAD8 case securable with padlocks |
| Principle of Operation | Electrostatic collection with silicon detector and alpha spectrometry |
| Built in Air Pump | Nominal 0.6-L/min flow rate. Inlet and outlet ports sealed when not in use |
| Measurement Accuracy | +/-5% absolute accuracy, 0% - 100% RH |
| Nominal Sensitivity |
Rapid mode: 0.40-cpm/(pCi/L), 0.011-cpm/(Bq/m³) Precise mode: 0.82-cpm/(pCi/L), 0.022-cpm/(Bq/m³) |
| Radon Concentration Range | 0 - 67,500-pCi/L (0 - 2,500,000 Bq/m³) |
| Intrinsic Background | 0.0015 ± 0.0004 pCi/L (0.06 ± 0.02 Bq/m³), for the life of the instrument |
| Recovery Time | Residual activity in Rapid Analysis Mode drops by factor of 1,000 in 30 minutes |
| Operating Ranges |
Temperature: 32° - 122°F (0° - 50° C) Humidity: 0% - 100%, non-condensing |
| Cycle Range |
User-controllable number of cycles, from 1 to unlimited, per test User-controllable cycle time, from 5 minutes to 24 hours |
| Capture Software |
Graphs radon, thoron, temperature, humidity, and barometric data over time. Statistical analysis tools track concentration averages and uncertainties. Automatic correction for humidity and other factors. Automatic RAD8 connection, data download, and real-time status monitoring. Control RAD8 operations from computer via direct or remote connection. Browse RAD8 data stored on Capture Cloud. Compatible with all major versions of Windows and macOS. |
| Dimensions | 12.5” x 10.1” x 6” (31.8 x 25.7 x 15.2 cm) |
| Weight | 7.4 pounds (3.35 kg) |
| Display | IPS 480 x 272 full color touchscreen, sunlight readable, wide viewing angle |
| Case Material | MIL-SPEC certified, IP67 rated |
| Battery | Rechargeable IATA-compliant 99-Wh lithium ion. 24 hours in Rapid Analysis Mode; 72 hours in Precise Analysis Mode |
| Power Supply | 11-15V DC (12V nominal) @ 2.5A, center pin positive |
| Comes With |
The RAD8 comes complete with the following components and accessories:
|
| Warranty | 2-year limited warranty |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
