RAPID-1840

RAPID-1840

Focus Microwaves

RAPID Active Tuner (4 - 18 GHz)

Focus Microwaves’ RAPID digital tuner is the heart of a precision, high-speed, load pull device characterization system. The RAPID has been developed by Focus’ UK subsidiary MESURO and is suitable for every phase of the design and production test cycle.

This series of new digital tuner products provide performance, reliability, and cutting edge features for a reasonable cost. The RAPID series is compatible with the hardware and software of existing labs, thereby allowing users to easily upgrade their existing systems.

The RAPID can be used as a standalone impedance synthesis and measurement system, or combined into a hybrid solution when paired with Focus’ MPT series harmonic tuners.

The passive tuners can be used to synthesise fixed harmonic impedances in a high speed fundamental active setup. With this modular configuration the user benefits from speed, increased tuning range for F0, CW, pulsed and modulated signals while reducing cost and simplifying the system.

Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Key Features
  • Dramatical improvement of Test-Bench Throughput. Ultra-fast impedance control and measurement (up to 50 tuning & measurement events/second including DC).
  • Modular Architecture designed for scalability. The innovative modular approach allows the user to re-use existing test equipment and add more functionality in the future.
  • Improved Modulated Measurement Capability. 100MHz real time bandwidth with wideband impedance control and/or circuit emulation. Ability to de-skew non-ideal tuner impedance over bandwidth.
  • Reduced testing cost. RAPID does not require an external VNA for calibration or measurement.
Pulse 200 ns
Minimum Frequency 4 GHz
Maximum Frequency 18 GHz
Dynamic Range 60 db
Product Type Active Tuner
More Information
Attribute Value
Data Sheet Click here to view
