Marki Microwave MFLP-00006CH, GaAs MMIC 12.94 GHz Lowpass Filter | APC

MFLP-00006CH

MFLP-00006CH

Marki Microwave

Passive GaAs MMIC 12.94 GHz Lowpass Filter

Bare Die Passive GaAs MMIC 12.94 GHz Lowpass Filter

The MFLP-00006CH MMIC lowpass filter is an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions.

Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MFLP-00006CH is available as a wire bondable die. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

MFLP-00006CH Applications:

  • Test and Measurement Equipment
  • SATCOM
  • Radar
  • RF Transceivers
Contact us for lead time

Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.

More Information
Attribute Value
Product Family Fixed_Filters
Size 2.4 x 1.6 mm
More Information
Attribute Value
Data Sheet Click here to view
