TCP202A
TCP202A
Tektronix
AC/DC current probe
The TCP202A is a high-performance, easy-to-use AC/DC current probe designed for use with a variety of oscilloscopes. The TCP202A is designed for direct connection to oscilloscopes with the TekProbe™ probe interface.
These AC/DC current probes provide sufficient performance to support 50 MHz measurement system bandwidth. The TCP202A provides a maximum 15 ADC + Peak AC measurement range. These probes also provide excellent accuracy to current levels as low as 10 mA, important for meeting today’s challenging current measurement needs.
Tektronix TCP202A Highlights
- 15 ADC + Peak AC maximum current capability
- 50 A peak pulse current capability
- Connects directly to oscilloscopes with the TekProbe™ interface
- Provides automatic units scaling and readout on the oscilloscope display
- Degauss button and thumbwheel for DC offset adjustment
- Safety Certified
Contact us for Lead Time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Segment | Current_Probes |
| Product Family | Current Probes |
| Key Features |
|
| Bandwidth | 3 Hz to 300 kHz |
| Whats Included |
|
| Applications |
|
| Rise Time | < 7 ns |
| Maximum DC Current | 15 A |
| Cable Length | 2 |
| Accessory Type | Current Probes |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
