U8552
U8552
Hioki
Voltage/Temp Unit U8552 - 30-channels voltage, temperature, and humidity measurement
More Information
| Attribute |
Value |
| Key Features |
- 30-channels, voltage, temperature (thermocouples), and humidity measurement
- Sampling rate of up to 20 ms with 30 channels (10 ms sampling is possible when the number of channels used is 15 or less)
- For DC voltage measurement and temperature measurement using thermocouples
|
| Basic Specifications |
| Connectable instruments |
Memory HiLogger LR8450 (Designed for use with plug-in units only)
Memory HiLogger LR8450-01 (Wireless LAN model) |
Operating temperature
and humidity |
-10°C to 50°C, 80% RH or less (no condensation) |
Storage temperature
and humidity |
-20°C to 60°C, 80% RH or less (no condensation) |
| Vibration resistance |
JIS D 1601:1995 5.3(1), Class 1A (passenger vehicle) equivalent |
| Accessories |
Instruction manual × 1, mounting screw × 2 |
Number of input
channels |
30 ch (Able to set voltage, temperature using the thermocouple, and humidity for each channel) |
| Input terminals |
Push-button type terminal block (2 terminals per channel) |
Measurement
target |
Voltage, temperature using the thermocouple, and humidity |
| Input type |
Scanning by semiconductor relays
All channels isolated (Not isolated when measuring with RTD, resistance, and humidity) |
|
| Instrument Type |
Voltage Logger |
