09185647914
09185647914
Harting
SEK-18 SV MA STD STR29 RKZ 64P PL3
Connectors, Male connector, Wave soldering termination, Rated current:1 A, Contacts: 64, Straight, Copper alloy, Sn over Ni, Termination side, Gold plated, Mating side, Performance level: 3, Thermoplastic resin (PBT), Grey
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
Attribute | Value |
---|---|
Product Segment | SEK Male standard |
Product Family | SEK |
Product Brand Name | 09 18 564 7914 |
Manufacturer | HARTING |
Customs tariff number | 85366990 |
Quantity Min | 50.0000 |
Quantity Interval | 50.0000 |
Country of origin | RO |
Number of poles | 64.0000 |
Material contact surface | Sn over Ni |
Material of insulation | Thermoplast |
Interlock type | With short levers |
Direction mating face | Standard |
Coating plug contact area | Tin (Sn) |
Number of rows | 2.0000 |
Type of PCB contacting | THT connection (Wave soldering) |
Grid dimensions 2 (mm) | 2.54 |
Pin length (mm) | 2.9 |
Locking system | Self-locking flange |
Material contact | Other copper alloys |
Fire resistance class | V0 |
Current Rating (A) | 1.0000 |
Temperature Range | -55 to 125 Deg. C |
