5600 HP Series 9U Rack Mount RF Test Enclosure (23 x 19 x 17 in)
Model 5604 HP 9U Rack Mount RF Test Enclosure
The Model 5604 HP is the high-performance rack-mount variant in the 5600 HP series, delivering 100 dB+ of RF isolation from 300 MHz to 6 GHz in a 9U rack-mountable format. Its dual-wall welded aluminium construction provides enhanced shielding effectiveness for demanding wireless device testing across development, production, and QA environments.
The 5604 HP includes passive waveguide ventilation with an externally mounted 110 VAC exhaust fan for thermal management. The interior is lined with ETS-Lindgren microwave absorber, and the dual-layer door features a precision braid-over-foam RF seal rated to more than 50,000 cycles. Interchangeable I/O panels offer flexible connectivity including SMA, N-type, DB9, USB 2.0, Ethernet (PoE), DC power, and AC power interfaces.
Key Features:
- 100 dB+ RF Isolation from 300 MHz to 6 GHz
- 9U Rack-Mountable Format: 58.42 x 48.26 x 43.18 cm (23 x 19 x 17 in)
- Dual-Wall Welded Aluminium Construction for Increased Performance
- Passive Waveguide Ventilation with 110 VAC Exhaust Fan
- Microwave Absorber Lined Interior
- Interchangeable I/O Connector Panels (5 Options Available)
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Frequency Range | 300 MHz to 18 GHz |
| Configuration | 9U Rack Mount |
| Shielding effectiveness | ≥100 dB @ 300 MHz to 3 GHz; ≥90 dB @ 3 GHz to 6 GHz; ≥80 dB @ 6 GHz to 18 GHz |
| Outer dimensions ( Lx W x H) | 58.42 cm x 48.26 cm x 43.18 cm (23 in x 19 in x 17 in) |
