61812

12kVA Single / Three-Phase Regenerative Grid Simulator Providing a Complete Energy-saving Solution

The power generated by the DUT during the test can be easily fed back to the grid, rather than dissipated as heat, which protects the environment and lowers the cost of operation. With this capability, the Chroma 61812 can be applied to applications in green energy products, such as PV inverters, energy storage systems (ESS), power conditioning systems (PCS), micro grids, power hardware-in-the-loop (PHIL), electric vehicle power supply equipment (EVSE), on-board charger (OBC) and bidirectional on-board charger (BOBC).

For regulatory testing, the Chroma 61812 can be applied to IEC 61000-3-2/-3- 3/-3-11/-3-12 (international regulations for AC voltage testing), IEEE 1547/IEC 62116 (international regulations related to green power generation), electric vehicle to grid (V2G) testing, electric vehicle to load (V2L) testing, electric vehicle to home (V2H) testing, energy storage system (ESS) testing.

Key Features

• High Power Density 15kVA in 3UH
• Intuitive Touch Panel Interface
• User-selectable single-phase or three-phase output
• Full 4 quadrant, fully regenerative up to 100% of output current rating
• Specifically designed for EV, PV inverter and Smart Grid related test applications
• Programmable slew rate settings for voltage and frequency
• Programmable voltage and current limits
• Turn on, turn off phase angle control
• Synchronise TTL signal of voltage changing
• LIST, PULSE, STEP mode functions for testing Power Line Disturbance (PLD) simulation
• Harmonics, inter-harmonics waveform synthesiser
• Comprehensive measurement capability, including current harmonics
• Universal AC Input Range
• Standard USB, LAN Interface
• Optional CAN, GPIB Interface
• Parallel output for higher power applications (Three phase only)
