7.010.981.001
7.010.981.001
Hummel
Crimp pin 1mm, machined
7.010.981.001 - Crimp pin 1mm, machined Also known as 7010981001. . Minimum mating cycles : > 1000
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Product Brand Name | 7010981001 |
| Manufacturer | Hummel |
| Additional Description |
|
| Length (mm) | 17.0000 |
| Weight (kg) | 0.00015 |
| Customs tariff number | 85366990 |
| EAN code | 4033878502310 |
| ETIM 7 | EC000796 |
| Packaging Unit | 100 |
| Characteristic of connection | Crimp |
| Insert | Pin |
| Signal contact diameter (mm) | 1.0000 |
| Minimum mating cycles | > 1000 |
| Crimp range | 0.08 – 0.75 mm² |
| Material contact surface | nickel, gold plated (0.25 µm) |
| Contact diameter | 1 mm |
| Crimp contact | Crimp pin signal 1 mm machined |
| Contact diameter crimping range (mm) | 1.7 |
| Material contact | Copper-zinc alloy |
| Cross section | 0.08 – 0.75 mm² |
| Crimp tool setting 1 (mm) | 0.6 |
| Crimp tool setting 2 mm | 0.65 |
| Crimp tool setting 3 (mm) | 0.67 |
| Crimp tool setting 4 (mm) | 0.71 |
| Crimp tool setting 5 (mm) | 0.75 |
| AWG | 18 – 28 |
| Suitable crimping tool | 7000900904 |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
