Narda Safety Test Solutions
External Unit Full Compliance For 9010F
With the external unit 9180 you can easily extend the frequency range of your receiver up to a maximum of 18 GHz.
Light and compact size, these units are equipped with a rechargeable Li-Ion that allows you to work for hours without any interference.
This external unit is fully compliant with CISPR16-1-1 requirements and meet all commercial and military standards for EMC measurements. All external units are fully compatible with the receivers of the 9010 Series, 9010 and 9010F / xxP
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Maximum Frequency | 18 GHz |
| Minimum Frequency | 6 GHz |
| Frequency Range |
6 GHz to 18 GHz Resolution - 100 Hz Reference frequency - < 2 ppm |
| RF Input |
Zin 50 Ω,N fem. (SMA) VSWR - 10 dB RF att. - < 2 0 dB RF att. - < 3 Attenuator - 0 dB to 45 dB (5 dB steps) Preamplifier gain - 20 dB |
| Max Input Level | 137 dBuV (1 W) without damage |
| Preselector |
Frequency ranges: 6 GHz to 9 GHz (Four bandpass filter) |
| IF Bandwidth |
3, 10, 30, 100, 300 kHz (-6 dB) |
| Noise Level |
Noise level, 6 to 18 GHz: |
| Spurious Response | < 20 dBuV |
| Measurement Accuracy |
S/N > 20 dB: 6 to 18 MHz ± 2.0 dB |
| I/O Interface | High Speed Optical |
| Operating Temperature | -5°C to 45°C |
| Power Supply |
10 - 15 Vdc, 2.5A |
| Product Category | Frequency Extension Unit |
