AMM-6702
AMM-6702
Marki Microwave
Broadband Amplifier
The AMM-6702 is a broadband MMIC LO buffer amplifier that efficiently provides high gain and output power over a 21-55 GHz frequency band. It is designed to provide a strong, flat output power response when driven with an input power at 0 dBm. It has built-in DC blocking capacitors on the input and output.
Contact us for lead time
Click below to request a quote for this item. Or for product advice, stock and lead time enquiries call our team on 0330 313 3220.
| Attribute | Value |
|---|---|
| Minimum Frequency | 21 |
| Minimum Input Power for Saturation [dBm] | +0 |
| Maximum Input Power for Saturation [dBm] | +5 |
| Saturated Output Power [dBm] | +21 |
| Small Signal Gain [dB] | 24 |
| OIP3 [dBm] | +27 |
| Amplifier Type | LO Driver Bare Die/Modules |
| Package | Bare Die and Module |
| Attribute | Value |
|---|---|
| Data Sheet | Click here to view |
